PRONAR ZKP 800 - νέος - NEW - 11967E

Pronar ZKP 800 is a double rotor rotary rakes with hydraulic regulation of working width from 7,0 to 8,0 m and manual width and height blockade. Turned linkage enables perfect steering of the rake. Lower links enable additional ground following behind the tractor. Front and rear independent wheels provide perfect following of the machine behind the tractor during taking turns. ZKP 800 double rotor rotary rakes fold hydraulically from working to transport position and vice versa. TECHNICAL DATA Working width min./max. [m] 7,0 / 8,0 Rotor diameter [m] 3,1 Dimensions in working position (Width min./max. | Length | Height)[m] 7,50 / 8,50 | 5,40 | 1,45 Dimensions in transportation position (Width | Length | Height(with pulled out fingers/with folded fingers)) [m] 2,80 | 5,40 | 4,20/3,55 Type of mounting attachment cat. I and II Number of rotors 2 Number of working arms on one rotor 11 Number of working fingers on one arm 4 Rotor wheels Pneumatic tandem axle, front torsion wheels 16x6,50-8 Drawbar torsion wheels Pneumatic 10,0/75-15,3 PTO revolutions [RPM] 540 Power requirement [HP] 80
